BWT bestprotect is a filter solution for water with special properties. It not only prevents the formation of limescale and gypsum, but also ensures a consistently high pH value.
BWT thereby protects the valuable machine technology from deposits and prevents corrosion problems on stainless steel parts. Moreover, this filter system delivers water with top sensory characteristics for producing high-quality hot beverages.
|BWT bestprotect type||S||V||XL||2XL|
|Connection thread (in/out), (1)||3/8"||3/8"||3/8"||3/8"|
|Inlet pressure, min. – max. in bar||2–8||2–8||2–8||2–8|
|Water temperature, min. – max. in °C||4–30||4–30||4–30||4–30|
|Ambient temperature, min. – max. in °C||4–40||4–40||4–40||4–40|
|Total height without bracket in mm, approx.||360||420||502||580|
|Total height with bracket in mm, approx.||385||445||527||600|
|Connection height in mm||306||366||448||520|
|Distance to floor in mm||65||65||65||65|
|Installation length in mm||125||125||125||125|
|Ø filter cartridge in mm||88||110||147||185|
|Weight in kg, approx. (dry/wet)||0.9/1.5||3.0/3.2||4.0/6.0||8.0/11.0|
|Order no. of filter cartridge||FS22N00A00||FS23N00A00||FS28N00A00||FS30N00A00|
(1) Connection thread options with BWT besthead FLEX
